Description
Microzone MC6C Mini 2.4GHz 6CH Remote Controller with MC6RE-V2/MC7RB-V2 Receiver for RC Aircraft Model Fixed Wing FPV Racer Drone
The Microzone MC6C Mini is a 2.4GHz 6-channel remote controller designed for RC aircraft, fixed-wing models, FPV racers, and more. It boasts an impressive control range of over 800 meters, with a frequency range of 2401 to 2478MHz. The controller supports electronic fine-tuning, low voltage alarms, and runaway protection settings, ensuring reliable performance. Compatible with multiple receivers including MC6RE-V2 and MC7RB-V2, it also supports various applications such as multi-axis and intelligent agricultural machinery. The compact design measures 160x80x165mm and weighs 470g, making it portable and easy to handle.
Microzone MC6C Mini 2.4GHz 6CH Remote Controller with MC6RE-V2/MC7RB-V2 Receiver for RC Aircraft Model Fixed Wing FPV Racer Drone
Description:
Brand: Microzone
Model: MC6C MINI
Number of channels: 6
Control range: >800m
Frequency range: 2401 – 2478MHz
Rocker dynamic range: 80%-120%
Fine-tuning method: Electronic fine-tuning
Transmitting power: 沌100mw
Input voltage: DC4.5-9V
Modulation mode: FSK
Remote control power supply requirements: 4 沁 5 batteries or 2S lithium batteries
Low voltage alarm: Yes
Analog Picking (PPM): Yes
Channel forward and reverse indication: Support
Runaway protection settings: Support
LED indication: Support
Support receivers: MC6RE-V2/MC7RB-V2/MC6RE/MC7RB/MC9002/E6R-E
Size: 160*80*165mm
Weight: 470g
Applications: Fixed-wing/Car/Boat/Multi-axis/Lawn mower/ Inteligent agricultural machinery
Receiver Specifications:
Model: MC6RE-V2 / MC7RB-V2 (Optional)
Applications: Fixed-wing/Car/Boat/RC Drone
Channel output: 6 PWM signals, 1 SBUS signal, 7 PWM signals, 1 SBUS signal
Frequency range: 2401 MHz-2478MHz
Control range: >800m
Receiver supply voltage: DC: 4.5-6V
SBUS signal: Support
Frequency pairing mode: Contact to frequency
Recovery performance: Fast signal recovery
Runaway protection settings: Support
Remote control support: 6C-MINI/C7-MINI/8B-MINI/C10-MINI
Antenna type: Extermal antenna | Built-in antenna
Antenna length: 110mm | /
Size: 37*23*13(mm) | 42*30*13(mm)
Weight: 7g
Package Included:
1 x MC6C MINI Remote Controller
1 x MC6RE-V2/MC7RB-V2 (Optional)
1 x Box
