SURPASS-HOBBY FLIER 32-bit 30A Brushless ESC with 5.5V/4A BEC for RC Airplanes, Programmable

-29%

SURPASS-HOBBY FLIER 32-bit 30A Brushless ESC with 5.5V/4A BEC for RC Airplanes, Programmable

Original price was: $23.10.Current price is: $16.50.

High-performance 32-bit microprocessor for faster speeds
Supports 30A continuous and 40A burst current
5.5V/4A BEC output for efficient power distribution
Compatible with 5-12NC/2-4S Lipo batteries
Multiple protection features for enhanced safety

SKU: RC1992679 Category: RC Airplane Parts Tags: 30A continuous ESC, 32-bit brushless ESC, 5.5V BEC output, ESC with multiple protections, high RPM motor support, programmable ESC for RC, RC airplane ESC, RC parts and accessories Brand: SURPASS-HOBBY

Description

SURPASS-HOBBY FLIER Series New 32-bit 30A Brushless ESC With 5.5V/4A BEC Support Programming for RC Airplane

The SURPASS-HOBBY FLIER Series 30A Brushless ESC is designed for RC airplane enthusiasts seeking high performance and reliability. Featuring a 32-bit microprocessor, it offers enhanced computing power and faster speeds. The ESC supports a continuous current of 30A and a burst current of 40A, making it suitable for high-demand applications. With a BEC output of 5.5V/4A, it ensures efficient power distribution to servos. The ESC is compatible with 5-12NC/2-4S Lipo batteries and includes multiple protection features such as start-up, over-heat, and low-voltage cutoff. Its smooth start-up and accurate throttle linearity enhance user control, while support for high RPM motors ensures versatility.

Specifications:
Brand Name: SURPASS-HOBBY
Type: FLIER 30A
Item: SP-300002-03
Continuous/Burst Current: 30A/40A
Battery Cell NiXX/Lipo: 5-12NC/2-4S Lipo
Weight: 25g
BEC Output: 5.5V/4A
Size(LxWxH): 60x25x10mm
Connector: 3.5mm
User Program: Yes
Features:
1. Adopting new generation craft on the MOSFET, low heat generation, withstand large current instantly, and high reliability.
2. Adopting high performance 32 bit microprocessor, stronger computing ability and faster running speed.
3. Super smooth start-up and accurate throttle linearity.
4. Higher driving efficiency and more energy-saving.
5. Adjustable SBEC 5V/6V output voltage 5V/6V provides more powerful to the servo. (40A/50A/60A/80A/100A have SBEC adjustable)
6. Multiple protections: Start-up, over-heat, low-voltage cutoff, signal loss, phase loss etc.
7. Support high RPM motors, and compatible with most motors in the market.
8. Support programming via LCD program card, easier and more convenient operation (Extra LCD program card needed, Click Here)
English Manual, Click Here
