Description
QX-Motor QF3538-2000KV 80mm 12 Blade 6S EDF Ducted Fan Unit With Brushless Motor CW/CCW For RC Airplane Fixed Wing
Overview:
QX-Motor focus on the research, development and production of EDF power system, adopts materials imported from Japan, with more efficient performance, dynamic balance within 10mg, high efficiency value, and can withstand 180 ?? high temperature.This 80mm EDF is equipped with QF3538-2000KV high-performance brushless DC motor, 12-blade forward and reverse propellers, with a thrust of up to 4kg, powerful and efficient! The temperature is low. It is the ideal choice for the majority of players!
Specifications:
Brand Name: QX-Motor
Item Name: 80mm 12 blade EDF
Version: CW, CCW (optional)
Motor: QF3538
KV: 2000
Configuration: 12N10P
Shaft Diameter: 6.0mm
Motor Diameter: 35mm
Weight: 335g
No. of Cells: 6S LiPo
Max. Continuous Power/10s: 2800W
Max. Continuous Current/10s: 112A
Test Data:
| Prop | Volts (V) | Amps (A) | Watts (W) | Thrust (g) | Thrust (oz) | Efficiency (g/W) | Efficiency (oz/W) | Throttle | Motor | ESC |
| 80mm EDF | 22 | 96 | 2112 | 3500 | 123.46 | 1.66 | 0.06 | 100% | QF3538-2000KV | 120A |
| 80mm EDF | 24 | 107 | 2568 | 4000 | 141.09 | 1.56 | 0.05 | 100% | QF3538-2000KV | 120 A |
English Manual, Click Here
Package Included:
1x QX-Motor QF3538-2000KV 80mm 12 Blade EDF
