Description
XXD A2217 950KV 1100KV 1250KV 1500KV 2300KV 2700KV Outrunner Brushless Motor for RC Airplane Fixed Wing
The XXD A2217 Outrunner Brushless Motor is engineered for RC airplane enthusiasts, offering a range of KV options from 950KV to 2700KV to suit various performance needs. Each motor is lightweight at 68g and features dimensions of 27.8 x 32mm, with a 4.0mm output shaft diameter. The motor is designed for optimal efficiency, with the 2300KV model achieving a peak current of 30A/60S and a maximum efficiency of 78%. This versatile motor provides reliable thrust and RPM across different voltages, making it an excellent choice for fixed-wing RC aircraft.
Specification:
Brand: XXD
Model: A2217 2217
KV: 950KV, 1100KV, 1250KV, 1500KV, 2300KV, 2700KV (optional)
|
KVParameters
|
950KV
Product Name: A2217KV950 Brushless Motor
Product Weight: 68g
Dimensions: 27.8*32mm
Output Shaft Diameter: 4.0mm
KV Value: 950KV
Test Data:
11V 16.9A 7130 RPM, Thrust 955g
10.5V 15.8A 6980 RPM, Thrust 897g
10V 14.9A 6760 RPM, Thrust 853g
9.5V 13.9A 6580 RPM, Thrust 792g
|
1100KV
Product Name: A2217KV1100 Brushless Motor
Product Weight: 68g
Dimensions: 27.8*32mm
Output Shaft Diameter: 4.0mm
KV Value: 1100KV
Test Data:
11V 19.5A 8450 RPM, Thrust 1012g
10.5V 17.4A 8220 RPM, Thrust 953g
10V 17.2A 8030 RPM, Thrust 903g
9.5V 15.9A 7730 RPM, Thrust 830g
|
1250KV
Product Name: A2217KV1250 Brushless Motor
Product Weight: 68g
Dimensions: 27.8*32mm
Output Shaft Diameter: 4.0mm
KV Value: 1250KV
Test Data:
11V 20.4A 10280 RPM, Thrust 1075g
10.5V 18.9A 9990 RPM, Thrust 995g
10V 17.8A 9620 RPM, Thrust 933g
9.5V 16.1A 9320 RPM, Thrust 855g
|
1500KV
Product Name: A2217KV1500 Brushless Motor
Product Weight: 68g
Dimensions: 27.8*32mm
Output Shaft Diameter: 4.0mm
KV Value: 1500KV
Test Data:
GWS8040HD:
11V 19.5A 13210 RPM, Thrust 963g
10.5V 17.9A 12730 RPM, Thrust 894g
10V 16.6A 12280 RPM, Thrust 816g
9.5V 15.2A 11820 RPM, Thrust 748g
GWS9050HD:
8V 18.6A 9030 RPM, Thrust 816g
7.5V 16.9A 8560 RPM, Thrust 739g
7V 15.1A 8080 RPM, Thrust 653g
6.5V 13.6A 7680 RPM, Thrust 578g
|
2300KV
Product Name: A2217KV2300 Brushless Motor
Product Weight: 68g
Dimensions: 27.8*32mm
Output Shaft Diameter: 4.0mm
KV Value: 2300KV
Maximum Efficiency: 78%
No-Load Current: 10V: 1.7A
Peak Current: 30A/60S
Optimal Efficiency Current: 8-28A (>70%)
Package Included:
1 x A2217 Brushless Motor
1 x 4mm Collet
1 x 22 Series Metal Mount
4 x Screws
