Description
SEQURE 12100 Brushless ESC Electric Speed Controller 5-12S Power Supply 100A BLHeli_32 / AM32 Firmware Support 128KHz PWM Frequency Suitable for Multi-Rotor Aircrafts Airplane Plant Protection Machine Boat RC Car Models
The SEQURE 12100 Brushless ESC is designed for high-performance applications, featuring a 32-bit STM32G071 processor with a 64MHz frequency and supporting up to 128KHz motor PWM. It efficiently dissipates heat using high-power MOSFETs and a CNC metal radiator, ensuring stable operation under high loads. This ESC supports various motion modes, including unidirectional and bidirectional, and offers multiple protections such as low voltage and temperature safeguards. It is compatible with all Dshot signals and supports PWM, Oneshot, and Multishot protocols. The ESC also features an RGB LED with customizable colors and is ideal for multi-rotor drones, RC cars, and more.
Product Description:
(1) Adopting 32-bit high-performance processor STM32G071, with a working frequency of up to 64MHz and maximum support 128KHz motor PWM frequency.
(2) Adopts high-power MOSFET, and combines with CNC metal radiator, this esc dissipates heat effectively under high current load and works stably & continuously.
(3) Supports multiple motion modes such as unidirectional, bidirectional, and braked motors.
(4) Supports multiple protections such as low voltage protection, temperature protection, locked rotor protection, and current protection.
(5) The ESC automatically detects the throttle signal when it is powered on, supports all Dshot signals, and also supports signal protocols such as PWM, Oneshot and Multishot.
(6) Visual programming parameter adjustment tool supports motor timing, throttle calibration, current detection, motor steering, telemetry signal and other settings.
(7) Onboard RGB LED color light settings, multiple LED colors can be customized.
(8) Widely used in model airplane plant protection machines, multi-rotor drones, RC model ships and cars.
SQESC 12100 Parameters:
Model:SQESC 12100
Processor:STM32G071
Input Voltage:DC 18V-50.4V侈5-12S Lipo佩
Continuous Current(good heat dissipation):100A
Maximum Current (good heat dissipation):180A
Support Firmware:BLHeli_32,AM32
Signal Protocol:Dshot (All),PWM,Oneshot,Multishot,etc.
Programming Parameter adjustment:Support
Throttle Calibration:Support
Timing Angle Setting:Support
Current Detection:Support
Telemetry Signal:Support
Motor Steering Settings:Support
RGB LED Color Lights:Support
Application Scenarios:Suitable for multi-axis drones, fixed-wing aircraft models, multi-rotor drones, plant protection machines, model ships, RC model cars, and rock crawlers.
Package Included:
1 x 12100 Brushless ESC (BLHeli-32 or AM32 optional)
