Furitek Lizard Pro 30A/50A Brushed/Brushless ESC with Bluetooth for Axial SCX24 1/24 Rock Crawler

Description

Furitek Lizard Pro 30A/50A Brushed/Brushless ESC with Bluetooth for Axial SCX24 1/24 Rock Crawler RC Car Vehicles Models Parts FUR-2073

The Furitek Lizard Pro ESC, model FUR-2073, is designed for Axial SCX24 1/24 rock crawler RC vehicles. This versatile ESC supports both sensorless brushless DC and brushed DC motors, configurable via a user-friendly app. The compact and lightweight unit, weighing just 3.7g, features FOC technology and a built-in BEC with 5V/6.5V 2.5A output. Compatible with 2S-3S LiPo batteries, it offers seamless plug-and-play functionality for AXIAL SCX24 crawlers. Easily programmable through an app on Android and iOS, it supports real-time telemetry up to 10Hz. Firmware updates are available with the Bluetooth module included.

Description:
Item Brand:FURITEK
Item Number:FUR-2073
Item Name:Brushed/brushless esc
Material:Metal and other electronic parts
Color:As picture shown
Product Size:ESC size is about 28*15.5mm
Product Weight:ESC weight is about 3.7g
Compatible Model:Axial SCX24 1/24 rock crawler rc car vehicle model
Features:
– Support sensorless brushless DC and brushed DC motor (config via app, default is brushless)
– FOC (Field-oriented control) technology
– Plug & Play designed for AXIAL SCX24 crawlers
– 5V/ 6.5V 2.5A Built-in BEC (config via app)
– Support 2S-3S lipo battery – Mini size and lightweight
– Super easy programming via App on both Android and IOS
– Firmware update available (Bluetooth module required)
– Real-time telemetry up to 10Hz – Ability to run with stock TX/RX or any other TX/RX
Specifications:
– Support 2S-3S lipo battery
– BIG BEC:5V or 6.5V 2.5A (Donã„™t need external BEC if use big Servo)
– Constant Current:30A
– Burst current:50A
– Build-in Switch power
Warning:
3s only works best with 2204 1400kv motors and 050 Brushed Motor
Furitek ESC only support: Komodo 2204 1400kv, Micro Komodo 3450kv, Mini Komodo 2000kv. Don’t run motors with high KV like 4100 on 3S

Package Included:
1 x Lizard PRO ESC
1 x Furitek Bluetooth
1 x Power Cable
1 x Heat Shrinkable Tube
1 x Servo to JST Receiver
