iFlight ELRS Handheld Gimbal Controller for DJI RS2/RS3/RS4 PRO, 2.4GHz 868/900MHz, Compatible with X8 Pro Max FPV Racing Drones

Description

iFlight 2.4GHz 868/900MHz ELRS Handheld Gimbal Controller for DJI RS2/RS3 PRO/RS4 PRO Handheld Gimbal X8 Pro Max FPV Racing Drones

The iFlight ELRS Handheld Gimbal Controller is designed for seamless compatibility with DJI RS2, RS3, and RS4 PRO handheld gimbals. Operating on a frequency of 2.4GHz, 868MHz, or 900MHz, this controller utilizes the ELRS protocol to wirelessly manage gimbal movements. It supports remote control functions such as recording and returning, enhancing your gimbal experience. Equipped with an ESP8285 MCU and an SX1281/SX1276 RF Chip, it offers reliable performance. The controller features a NATO interface and accepts a 5V input voltage. With a compact design weighing just 28g, including the antenna, it is both lightweight and portable.

iFlight 2.4GHz 868/900MHz ELRS Handheld Gimbal Controller for DJI RS2/RS3 PRO/RS4 PRO Handheld Gimbal X8 Pro Max FPV Racing Drones
Features:
Suitable for DJI handheld gimbals, use the ELRS protocol remote control to wirelessly control the gimbal movement direction, support the use of the remote control switch to control the gimbal recording, return and other functions.
Specifications:
Brand: iFlight
Item: Handheld Gimbal Controller
Frequency: 2.4GHz ISM or 868MHz/900MHz (ELRS)
MCU: ESP8285
RF Chip: SX1281/SX1276
RF Connector: Module Outer Screw Inner Pin/Antenna Inner Screw Inner Hole
Firmware Name: iFlight 2.4GHz Nano RX/iFlight 900MHz Nano RX
Firmware Version: ExpressLRS V3.4.3
Output Protocol: DJI RS Pro
Firmware Update: UART or WIFI
Connector: NATO Interface
Input Voltage: 5V
Weight: 28g (including antenna)
Dimensions: 47*31*12mm
Applicable Gimbal Models: for DJI RS2/RS3/RS3 PRO/RS4/ RS4 PRO Handheld Gimbal

Package Included:
1 x iFlight Handheld Gimbal Controller
