Mini Brush ESC 20/30A with Brake for 1/16 1/18 RC Car Boat Models
Price range: $9.83 through $10.66
- 20A brush motor speed controller with brake
- Supports forward, reverse, and brake functions
- Compatible with 130/180/260/280/380 brush motors
- Operates within 3.0V to 9.4V voltage range
- Compact size: 35.0 x 22.0 x 6.0mm
You May Also Like
Description
20/30A Mini Brush ESC Brake 1/16 1/18 for Climbing RC Car Boat Model Spare Parts
The 20A Mini Brush ESC with brake is designed for RC enthusiasts who need precise control for their cars, boats, or tanks. This speed controller supports forward, reverse, and braking functions, operating efficiently within a voltage range of 3.0V to 9.4V. Its compact dimensions of 35.0 x 22.0 x 6.0mm make it an ideal fit for various models. With a constant current capacity of 20A and a maximum of 25A for up to 30 seconds, this ESC is compatible with 130/180/260/280/380 brush motors. It runs on Li-Po 2S or Ni-Mh/Ni-cd 4-7 cell inputs, ensuring versatile power options for your RC projects.
Usage:
RC ESC 20A Brush Motor Speed Controller w/ Brake for RC Car Boat Tank
Description:
1pcs 20A brush speed controller.
Function: forward, reverse, brake
working voltage: 3.0V—9.4V.
Diaensions(L*W*H): 35.0*22.0*6.0mm
Current(A): 20A
Driver frequency: 2KHz
Input: Li-Po 2S / Ni-Mh/Ni-cd 4-7cell
Constant current 20A Max 25A< 30s Pulsed 50A< 5s
Brake On / with brake
This ESC can work with 130/180/260/280/380 Brush Motor
Size:20*20 MM
Package Included:
1 x Brush Motor Speed Controller
