Racerstar BR2306S 2700KV Brushless Motor for X210 X220 250 FPV Racing Drones, 2-4S Compatible

Description

Racerstar Racing Edition 2306 BR2306S 2700KV 2-4S Brushless Motor for X210 X220 250 RC Drone FPV Racing

The Racerstar BR2306S 2700KV Brushless Motor is designed for FPV racing drones like the X210, X220, and 250 models. With a high RPM/V of 2700KV, this motor ensures superior performance and speed. It features a robust stainless steel motor shaft and long-lasting Japanese NMB ball bearings for enhanced durability. The motor’s CNC machined aluminum case and oxygen-free copper wire provide excellent power efficiency and reliability. Compatible with 2-4S LiPo batteries, it delivers outstanding thrust and efficiency, making it more powerful than the BR2205S model. Ideal for racing frames, it has been tested with 14.8V voltage and 5045 propellers, achieving a load current of 35A and a pull of 1070g.

Description:
Brand: Racerstar
Item name: BR2306S 2700KV Brushless Motor
RPM/V: 2700KV
Height: 33.5mm
Width: 28.5mm
Shaft diameter: M5
Motor mount hole size: M3
Weight: 33.5 grams
Voltage: 2-4S
Battery: 2-4S lipo battery
Internal resistance:
Usage: X210 X220 250 280 FPV Racing Frame
Tested with 14.8V voltage 5045 propellers:
Load current: 35A
Pull: 1070g
Power: 490W
Efficiency: 2.2 (g/W)
CW screw thread motor comes with red cap
Features:
Stainless steel motor shaft
Long life Japanese NMB ball bearings
Oxygen free copper wire
CNC machined aluminum case
More powerful than BR2205S

Package Included:
1 x BR2306S 2700KV Brushless Motor
or
4 x BR2306S 2700KV Brushless Motor
