FlySky FS-CGPS01 GPS 72CH i.bus Port High Sensitivity Short Acquisition Time Strong Antiinterference Ability Support GPS Galileo Beidou Satellite System
FlySky FS-CGPS01 GPS 72CH i.bus Port High Sensitivity Short Acquisition Time Strong Antiinterference Ability Support GPS Galileo Beidou Satellite System
OVERVIEW:
The FS-CGPS01 adopts NEO-M8Q chip, supports GPS, Galileo, Beidou and other satellite systems, and features high sensitivity, short acquisition time, strong antiinterference ability and low power consumption.
The FS-CGPS01 can be used for fixed wings, traversal machines (5 inch, 7 inch larger models) training to view satellite quantity, ground distance, ground speed, height, direction, longitude, latitude, etc. By viewing the ground distance, the height and ground speed can provide some reference data for evaluating battery life or training effects, and can provide data on the aircraft in the aircraft by the ground distance and direction. For the vehicle model, the speed can be measured by GPS.
Specification:
Brand Name: FlySky
Item Name: FS-CGPS01 GPS
Model: FS-CGPS01
Master Chip: NEO-MBQ
Channels: 72
Satellite Systems Supported: GPS | Galileo | Beidou
Numbers of Statellites Searched: > 12
Tracking: -167dBm
Capture: -160dBm
Cold Start: -148dBm
Hot Start: -157d Bm
Cold Start Time: Average 265
Hot Start Time: Average Is
Positioning Accuracy: 0.3 degrees
Accuracy of Speed Measurement: 0.05 m/s
Time Accuracy: RMS 99% 30ns
LED : Yes
Frequengy Range: 1559NH – 1606 MHZ
Update Frequency: 10Hz
Data Format : i-BUS
Input Power: 4.0 ~ 8.4V
Temperature Range: -15??C~ +60??C
Humidity Range: 20%6 ~ 95%6
Dimensions : 52.4*50^18.5mm
Weight: 30g
Certification: CE.FCC
Attention:
Ensure that the product and model are installed correctly before use, otherwise the model may be seriously damaged.
Keep the GPS installed horizontally, install it higher than the machine body as far as possible, and keep it away from high current and strong magnetic objects;
Avoid overexertion to damage any objects;
If the bracket is not installed, please stick the GPS to the model frame using 3M.
If you need to install the bracket, please stick the GPS on the bracket using 3M and keep the following installation status.
Package Included:
1 x FS-CGPS01 GPS
