XF C-20D Vertical 19mm 2-Axis FPV Gimbal for DJI O3, WalkSnail Avatar, RC Drones, High-Torque Motors, Stabilization

Description

XF C-20D Vertical 19mm 2-Axis FPV Gimbal Supports DJI O3 Unit WalkSnail Avatar for FPV RC Drones

The XF C-20D Vertical 2-Axis FPV Gimbal is engineered for superior stability and control, compatible with DJI O3, Walksnail Avatar, and 19mm analog cameras. It features a robust 2-axis mechanical stabilization structure with high-torque motors to minimize vibrations and air impact. The gimbal supports multiple digital FPV systems and offers versatile mounting options for downward or upward installation. Its compact design is crafted from high-performance polymer, ensuring lightweight efficiency. With Headtracker support and various control ports, including UART, S.BUS, CRSF, and PWM, the C-20D delivers an immersive first-person experience. Suitable for RC cars, FPV fixed-wing planes, and realistic RC planes, it operates on a wide voltage input of 7.4 to 26.4 VDC.

Description:
The C-20D Vertical 2-axis FPV Gimbal is compatible with a variety of digital FPV systems such as DJI O3, Walksnail Avatar, Walksnail Moonlight, and 19mm wide analog cameras. With a 2-axis mechanical stabilization structure and high-torque motors, the C-20D is able to provides an extreme stabilization effect against the vibration and highspeed airimpact.With the Headtracker, the C-20D provides an immersive high-quality firstperson control experience.
Feature:
– Compatible with a variety of digital FPV systems such as DJI O3, Walksnail Avatar, Walksnail Moonlight, and 19mm wide analog cameras or other devices.
– The main body is made of high performance polymer, which is extremely compressed in size and weight.
– With a 2-axis mechanical stabilization structure and high-torque motors, the C-20D is able to provides an extreme stabilization effect against the vibration and high-speed airimpact.
– Multiple stabilization modes are suitable for a variety of platforms such as RC cars, FPV fixed-wing planes and realistic RC planes.
– Supports Headtracker, UART(private protocol &MAVLink), S.BUS, CRSF and PWM control.
– Can be mounted whether downward or upward.
– 7.4~26.4 VDC wide voltag input.
Specification券
Brand: XF
Item Name: C-20D Vertical 2-Axis FPV Gimbal

Product Name:

C-20D

Dimensions:

42 x50.9×55.7mm

Weight:

36g

Operating Voltag:

7.4~ 26.4VDC

Power:

0.25W (AVGl) / 8W (Stall)

Mounting:

Downward/ Upward

Control Port:

Headtracker/ UART (private protocol &MAVLink)/ S.BUS / CRSF / PWM

Gimbal

Gimbal Type:

2-axis Mechanical Stabilization

Angular Accuracy:

呼0.005‵

Controllable Rang

Pitchh: -35‵~+175‵,Yaw: 呼145‵

Max Rotation Speed:

呼1500‵/s

Camera Suitability

Maximu Weight:

20g

Maximu Width:

19mm

Package Included:
1 x C-20D Vertical 2-Axis FPV Gimbal
1 x J1.0 Parameter Adjustment Module
1 x Installation Tools
