Description
JX Servo PDI-HV0903MG 9.4g High Torque Digital Standard Servo For RC Model Airplane
The JX Servo PDI-HV0903MG is a high-performance digital standard servo designed for RC model airplanes. Weighing just 9.4g, it offers exceptional torque and speed, operating efficiently between 6V and 7.4V. With a dead band of 2米s and a control system based on pulse width control, this servo ensures precise movements. It features a robust stall torque of 2kg.cm at 6V and 2.6kg.cm at 7.4V, with operating speeds of 0.09sec/60～ and 0.07sec/60～ respectively. The servo is equipped with a direct drive potentiometer, a 150mm JR/Futaba connector wire, and dual bearings for smooth operation. Its compact dimensions of 23.5X8X24mm make it ideal for various RC applications.
JX Servo PDI-HV0903MG 9.4g High Torque Digital Standard Servo For RC ModelDescription:
Brand name: JX
Item number: PDI-HV0903MG 9.4g High Torque Digital Standard Servo
Dead band: 2μs
Control System: +Pulse Width Control
Working frequence: 1520μs / 330hz
Operating Voltage: DC6~7.4 V
Operating Temperature Range: -10 to + 60°C
Operating Speed (6V): 0.09sec/60°
Operating Speed (7.4V): 0.07sec/60°
Stall Torque (6V): 2kg.cm
Stall Torque (7.4V): 2.6kg.cm
Potentiometer Drive: Direct Drive
Dimensions: 23.5X8X24mm
Weight: 9.4g (0.33oz)
Connector Wire Length: JR/Futaba 150 mm
Bearing: 2BB
Package Included:
1 x JX PDI-HV0903MG 9.4g High Torque Digital Standard Servo
