Description
SKYRC T100 DUAL 5A 2X50W Balance Charger for 2-4S LiPo/LiIon/LiFe/LiHV Battery
The SKYRC T100 is a versatile twin-channel charger designed for simultaneous charging of different battery chemistries, including LiPo, LiFe, LiIon, LiHV, NiMH, NiCd, and Pb. Its compact, sleek design features convenient front-loading plug-in ports for balancing and XT60 connections. With a powerful output of up to 100W and a charging current of 5A, it ensures efficient charging. The charger includes AGM and cold charge modes, making it suitable for charging Pb and AGM batteries even in cold conditions. It supports a wide range of battery capacities and offers safety features such as a safety timer and discharge cut-off voltage.
SkyRC T100 is a twin-channel charger with two independent circuits which can charge batteries of varying chemistries (LiPo / LiFe / Lilon / LiHV / NiMH / NiCd / Pb) simultaneously. Its sleek design allows easy front-loading plug-in convenience of balancing and XT60 ports. It is not only compact in size but also powerful in output with maximum 100W charging power and 5A charging current which makes charging more efficient. With the new AGM and cold charge modes, the user is free to charge their PB and AGM batteries on cold days.
Specifications:
Case Material: Plastic
Case Size: 90x100x127mm
Weight: 500g
Display Type: 2x16LCD
Display Backlight: Blue
Input Voltage: AC 100-240V
Charge Wattage: 50Wx2
Battery Types/Cells:
LiPo/LiFe/LiIon/LiHV: 2-4 cells
NiMH/NiCd: 6-8 cells
Pb:6/12V
Battery Capacity Range:
LiPo/LiIon/LiFe/LiHV:100-50000mAh
NiMH/NiCd:100-50000mAh
Pb: 100-50000mAh
Charge Voltage:
LiPo: 4.18-4.25V/cell
LiFe: 3.58-3.7V/cell
LiIon: 4.08-4.2V/cell
LiHV: 4.25-4.35V/cellNiMH/NiCd: peak detection: 3-15mV/cell ; Default: 4mV/cell
Discharge Cut-off Voltage:
LiPo:3.0-3.3V/cell
LiFe:2.6-2.9V/cellLiIon: 2.9-3.2V/cell
LiHV: 3.1-3.4V/cellNiMH/NiCd:0.1-1.1V/cell
Charge Current: 0.1A-5.0A
Balance Cells: 2-4 cells
Balance Current: 300mA/cell
Safety Timer: 1-720minutes & OFF
Charge Method:CC/CV for Lithium batteries.
CC/CV and float charge for PB batteries.
Packaging included:
1XSKYRC Battery Charger
SkyRC T100 is a twin-channel charger with two independent circuits which can charge batteries of varying chemistries (LiPo / LiFe / Lilon / LiHV / NiMH / NiCd / Pb) simultaneously. For Pb battery, AGM Charge and Cold Charge mode are available.
Package Included:
1 x SKYRC T100 Battery Charger
