Flysky FS-R11P 2.4GHz 11CH Receiver, ANT Protocol, PWM PPM i-BUS S.BUS, Compatible with FS-G11P Transmitter for RC Car Boat

Description

Flysky FS-R11P 2.4GHz 11CH ANT Protocol PWM PPM i-BUS S.BUS Receiver Compatible with FS-G11P Transmitter for RC Car Boat Tank

The Flysky FS-R11P is a versatile 11-channel receiver based on the ANT protocol, designed for seamless communication with the FS-G11P transmitter. It features an external single antenna and supports multiple signal outputs, including PWM, PPM, i-BUS, and S.BUS. With a compact design, it fits easily into various RC cars or boats, providing a reliable communication range of up to 300 meters without interference. The receiver operates efficiently across a voltage range of 3.5 to 9V DC, is waterproof with a PPX4 rating, and supports firmware updates for enhanced functionality. It is certified with CE and FCC, ensuring compliance with international standards.

Flysky FS-R11P 2.4GHz 11CH ANT Protocol PWM PPM i-BUS S.BUS Receiver Compatible with FS-G11P Transmitter for RC Car Boat Tank
Description:
FS-R11P based on ANT protocol is a receiver which provides 11-channel and bidirectional transmission, featuring external single antenna and PWM, PPM, i-BUS or S.BUS signal output, and a compact design. It can be adapted to a variety of model cars or boats.
Specification:
Brand: Flysky
Product Name: FS-R11P Receiver
Number of PWM Channels: 11CH
RF: 2.4GHz ISM
Maximum Power: <20dBm (e.i.r.p.) (EU)
Antenna: External single antenna
Distance: √ 300m (Ground distance without interference)
RF Protocol: ANT
Resolution: 4096
Data Output: PWM/PPM/i-BUS/S.BUS
Operating Voltage: 3.5 ~ 9V/DC
Firmware Update: Supported
Temperature Range:-10﹠ ~ +60﹠
Humidity Range: 20% ~ 95%
WaterProof: PPX4
Dimensions:37.0mm*25mm*13.3mm
Weight: 10g
Certifications: CE, FCC ID: 2A2UNR11P00
Compatible Transmitters: FS-G11P (Adapts transmitters with ANT protocol)
Compatible RC Models: Cars or boats

Package Included:
1 x Flysky FS-R11P Receiver
