Description
GEPRC GEP M1025 Series M10 Chip GPS Module for RC Drone FPV Racing Helicopter Quadcopter RC Airplane Car
The GEPRC GEP-M1025 Series GPS Module is a fully upgraded GPS solution designed for RC drones, FPV racing, helicopters, quadcopters, and RC airplanes. Featuring the advanced u-blox M10 chip, it supports GPS, BDS, Galileo, QZSS, and SBAS joint positioning with up to 32 satellites for fast and stable connections. The 25mm ceramic antenna enhances signal reception, while the built-in Flash chip and Farad capacitor ensure quick hot starts and configuration saving. Optional magnetometer and barometer integration offer precise azimuth and altitude data, catering to a wide range of model products. The module is equipped with an onboard indicator light for ease of use.
Summary:
The GEPRC GPS series product line has been fully upgraded. The GEP-M1025 series of GPS products based on u-blox M10050 chip and using 25*25mm antenna are now launched.
The GEP-M1025 series GPS positioning module uses u-bloxㄙs M10 chip solution and supports GPS+BDS+Galileo+QZSS+SBAS joint positioning, up to 32 satellites. 25*25mm ceramic antenna provides better reception capabilities. Built-in Flash chip and Farad capacitor can save configuration parameters and quickly hot start.
Optional QMC5883L/IST8310 magnetometer and DPS310/MS5611 barometer. A variety of matching solution provide accurate azimuth pointing and sensitive altitude change data. It can meet the needs of most FPV quadcopters , multi-rotor, fixed wing and other model products.
Specifications:
Name: GPS Module
Model: M1025 / M1025Q / M1025 DQ / GEP-M1025 MQ / M1025I / M1025 DI / M1025-MI
Diffirence:
GPS Parameters
Features:
1. u-blox M10 series chip
2. GPS+BDS+Galileo+QZSS+SBAS joint positioning
3. Fast positioning speed,Up to 32 satellites
4. Stable connection quality
5. 25*25mm antenna size, better signal receiving performance
6. Built-in Flash chip and Farad capacitor
7. Onboard indicator light, easy to use
8. Optional integrated magnetometer+barometer, more collocation scheme
Package Included:
1 X GPS Module
1 X Terminal Wire
1 X GPS Module Instruction Manual
1 X Geprc Sticker
1 X Heat Shrink Tubing
