HOTA T8 650W 22A XT60 1-8S Intelligent Charger & Checker for RC Devices

Description

HOTA T8 650W 22A XT60 1-8S Intelligent Charger Checker for a wide range of devices

The HOTA T8 Intelligent Charger & Checker is a versatile tool designed for a wide range of RC devices. With an input voltage range of DC 7.0~35.0V and a maximum power capacity of 650W, it supports charging and discharging at 0.1-22A. This device is compatible with multiple battery types, including Smart Battery, LiHv, LiPo, LiFe, and more. It features a 2.8-inch IPS screen with 260,000 colors for easy monitoring. The charger also includes a USB-A output of 5V at 2.1A for additional connectivity. Its compact design and intelligent features make it an essential tool for hobbyists and professionals alike.

Specification:

DC 7.0~35.0V@MAX 27A

Power Charge

0.1-22A@650W

Discharge Power

0.1-22A@650W Recyle External

0.1-3A@20W Normal mode

Balance Current

1000mA@4.2V

Storage Temperature

-20~60～⊥

Operating Temperature

0~40～⊥

Screen Size

2.8′ IPS 320℅240 260000 colors

USB-A Output

5V @ 2.1A Upgrade

Battery Type

Smart Battery/LiHv/LiPo/LiFe/Lilon/Lixx/LTO : 1~8S

NiZn/NiCd/NiMH:1~20S

PB: 1~12S

Eneloop : 1~20S

Measurer

PWM

880us-2200us@20-400Hz

PPM

880us-2200us*8CH@20-50Hz

SBUS

880us-2200us*16CH@20-100Hz

Voltage

1.0V-5.0V@1-8S

Internal resistance

1-99mR@1-8S

ESC

1-20A@1-35V MAX650W

Output

PWM

500us-2500us@20-1000Hz

PPM

880us-2200us*8CH@50Hz

SBUS

880us-2200us*16CH@74Hz
