Description
FrSky TW GR8 Dual 2.4G 8/24CH PWM Telemetry & Variometer Receiver FBUS / S.Port SBUS Output for FPV RC Racer Drone
The FrSky TW GR8 Dual 2.4G 8/24CH PWM Telemetry and Variometer Receiver is designed for FPV RC racer drones, offering enhanced signal stability and long-range communication. It features a unique TW protocol that integrates dual active 2.4G frequency bands simultaneously, ensuring reliable signal control without the need for a standby receiver. This receiver is equipped with a high-precision variometer, providing accurate altitude and vertical speed data, making it ideal for glider pilots. With 8 PWM output channels, SBUS In & Out, and telemetry support via FBUS/S.Port, the TW GR8 simplifies model builds by reducing wiring complexity and supports bidirectional transmission.
FrSky TW GR8 Dual 2.4G 8/24CH PWM Telemetry & Variometer Receiver FBUS / S.Port SBUS Output for FPV RC Racer Drone
TWIN series TW GR8 receiver features a new stable TW protocol that benefits from simultaneously integrating dual active 2.4G frequency bands. The TW active-active protocol is different from the general active-standby redundancy solution (where one receiver takes over signal control only when the other is in Failsafe mode), with the TW protocol, dual 2.4G frequency bands are active on the TW series receiver at the same time.This receiver is designed for RC users who want to benefits from resiliency and long-range in their radio communications,typically up to tens of kilometers is achievable. TW GR8 receiver features an upgraded high-precision variometer that gives pilots quick, accurate altitude and vertical speed data, and is ideal for any type of glider pilot.The TW GR8 receiver is equipped with 2℅2.4G antennas. The signal ports include both SBUS In & Out channel and 8 PWM output channel ports. It also supports telemetry functions through FBUS /S.Port. By setting the TW GR8 to use FBUS protocol in the ETHOS system, the signal control and telemetry can be connected to any device that supports FBUS protocol through only one line to achieve bidirectional transmission, also simplifying the model build using fewer wires.
Description:
Brand: FrSky
Model: TW GR8
Item: Dual 2.4G Receiver
Frequency: Dual 2.4GHzDimension: 54*20*10mm (L*W*H)Weight: 9.8gOperating Voltage: 3.5-10V (Please ensure the supplied voltage exceeds 2.8V during the use.)Operating Current: 80mA@5VVariometer Measurement Range每 Altimeter Range & Resolution: 每 700m to 10000m & 0.1m每 Vertical Speed Range: ㊣10m/sVoltage Measurement Range via AIN2 (External device): 0-36VAntenna Connector: IPEX4Compatibility: TWIN series Radio & RF module in TW mode.Features:
* Simultaneous working dual 2.4G TW mode;
* High-precision variometer sensor;
* Black-Box function;
* Long control range (Range varies based on the RF Power settings.);
* Over-The-Air (OTA) FW update;
* 8 PWM channel ports;
* SBUS Out port (Supports 16CH / 24CH mode);
* SBUS In port (Supports Signal Redundancy);
* FBUS / S.Port
Package Included:
1 x FrSky TW GR8 Dual 2.4G Receiver
