AKK FX2 Ultimate Mini FPV Transmitter 5.8GHz 40CH, 25mW/200mW/600mW/1200mW Power, Smart Audio, MMCX Connector

Description

AKK FX2 Ultimate Mini International 5.8GHz 40CH 25mW/200mW/600mW/1200mW Switchable FPV Transmitter

The AKK FX2 Ultimate Mini International Version is a high-performance FPV transmitter designed for RC enthusiasts. It operates on 5.8GHz with 40 channels and switchable output power levels of 25mW, 200mW, 600mW, and 1200mW. This compact transmitter is equipped with Smart Audio for seamless OSD configuration and features a convenient one-button frequency and power setup. It supports input voltages from 7V to 26V and provides a 5V/12V output for cameras. The MMCX antenna connector and solder pads ensure easy integration. Weighing just 8g and measuring 36x22mm, it is ideal for lightweight builds. Please note that usage of certain frequencies is restricted by the FCC, and an amateur radio license is required for legal operation in the USA.

Description:Brand name: AKKItem name: FX2 Ultimate Mini International VersionInput voltage: 7V to 26V
Extra features: Smart audio 1200mW
Power supply: 5V/12V output for camera
Output power: 25/200/600mW, 1200mW
Antenna connector: MMCX
Cable connector: Solder pads
Dimension: 36x22mm, 30.5 stackable hole
Weight: 8g (excluding antenna)
Features:
* Support Smart audio
* 25/200/600/1200mW power switchable
* One button frequency and power setup
* OSD configuration using smart audio
* 7-26V input with 5V output for camera
* With MIC
Notice: 5645/5925/5945 (E4/E7/E8) are not available due to FCC regulation. Selecting 5645/5925/5945 (E4/E7/E8) will be invalid action. Note: 37 channels are all above 5650 and below 5925MHz, which are legal to use in the USA with an amateur radio license. This equipment is being sold under FCCㄙs amateur radio rules.Operators must require amateur radio license to operator legally in the US. Use of amateur equipment without a license or use of equipment on restricted frequencies could subject the operator to significant fines by the FCC.By purchasing this equipment, the user isagreeing that they understand these responsibilities and will operate the equipment legally. More information related to ARL, please go to
http://www.arrl.org/getting-licensed.
Pacakge Included:1x VTX
1x pigtail
1x cable

Package Included:
1 x VTX
1 x Pigtail
1 x Cable
