Aircraft
Takeoff Weight
< 249g
|
Dimensions
Folded (without propellers): 148沁94沁64 mm (L沁W沁H)
Unfolded (with propellers): 298沁373沁101 mm (L沁W沁H)
|
Max Ascension Speed
5 m/s (S Mode)
5 m/s (N Mode)3 m/s (C Mode)
|
Max Descent Speed
5 m/s (S Mode)
5 m/s (N Mode)3 m/s (C Mode)
|
Max Horizontal Speed
(near sea level, no wind)
16 m/s (S Mode)
12 m/s (N Mode)12 m/s (C Mode)
|
Max Takeoff Altitude
With DJI Mini 4 Pro Intelligent Flight Battery: 4000 m
With DJI Mini 3 Series Intelligent Flight Battery Plus: 3000 m
|
Max Flying Time
34 mins (with Intelligent Flight Battery and measured while flying at 21.6 kph in windless conditions)
45 mins (with Intelligent Flight Battery Plus and measured while flying at 21.6 kph in windless conditions). Only available in select countries.
|
Max Hovering Time
30 mins (with Intelligent Flight Battery, no wind)
39 mins (with Intelligent Flight Battery Plus, no wind)
|
Max Flying Distance
18 km (with Intelligent Flight Battery and measured while flying at 40.7 kph in windless conditions at 20 meters above sea level)
25 km (with Intelligent Flight Battery Plus and measured while flying at 44.3 kph in windless conditions at 20 meters above sea level)
|
Max Wind Speed Resistance
10.7 m/s (Level 5)
|
Max Tilt Angle
35‵
|
Internal Storage
2 GB
|
Operating Temperature
-10‵ to 40‵ C (14‵ to 104‵ F)
|
GNSS
GPS + Galileo + BeiDou
|
Hover Accuracy Range
Vertical: 呼0.1 m (with Vision Positioning), 呼0.5 m (with GNSS Positioning)
Horizontal: 呼0.1 m (with Vision Positioning), 呼0.5 m (with GNSS positioning)
|
Gimbal
Mechanical Range
Tilt: -135‵ to 80‵
Roll: -135‵ to 45‵
Pan: -30‵ to 30‵
|
Controllable Range
Tilt: -90‵ to 60‵
Roll: -90‵ or 0‵
|
Stabilization
3-axis mechanical gimbal (tilt, roll, pan)
|
Max Control Speed (tilt)
100‵/s
|
Angular Vibration Range
呼0.01‵
|
Sensing System
Sensing Type
Omnidirectional binocular vision system, supplemented with a 3D infrared sensor at the bottom of the aircraft
|
Forward
Measurement Range: 0.5-18 m
Detection Range: 0.5-200 mEffective Sensing Speed: Flight Speed 沌 12 m/sFOV: Horizontal 90‵, Vertical 72‵
|
Backward
Measurement Range: 0.5-15 m
Effective Sensing Speed: Flight Speed 沌 12 m/sFOV: Horizontal 90‵, Vertical 72‵
|
Lateral
Measurement Range: 0.5-12 m
Effective Sensing Speed: Flight Speed 沌 12 m/sFOV: Horizontal 90‵, Vertical 72‵
|
Upward
Measurement Range: 0.5-15 m
Effective Sensing Speed: Flight Speed 沌 5 m/sFOV: Front and Back 72‵, Left and Right 90‵
|
Downward
Measurement Range: 0.3-12 m
Effective Sensing Speed: Flight Speed 沌 5 m/sFOV: Front and Back 106‵, Left and Right 90‵
|
3D Infrared Sensor
Measurement Range: 0.1-8 m (reflectivity > 10%)
FOV: Front and Back 60‵, Left and Right 60‵
|
Operating Environment
Forward, Backward, Left, Right, and Upward:
Surfaces with discernible patterns and adequate lighting (lux > 15)Downward:Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 15)
|
Camera
Image Sensor
1/1.3-inch CMOS
Effective Pixels: 48 MP
|
Lens
FOV: 82.1‵
Format Equivalent: 24 mm
Aperture: f/1.7
Focus Range: 1 m to ?
|
ISO Range
Video
Normal and Slow Motion:100-6400 (Normal)100-1600 (D-Log M)100-1600 (HLG)
Night:100-12800 (Normal)
Photo12 MP: 100-640048 MP: 100-3200
|
Shutter Speed
12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure)
48MP Photo: 1/8000-2 s
|
Max Image Size
8064沁6048
|
Still Photography Modes
Single Shot: 12 MP and 48 MP
Burst Shooting:12 MP, 3/5/7 frames48 MP, 3 framesAutomatic Exposure Bracketing (AEB):12 MP, 3/5/7 frames at 0.7 EV step48 MP, 3 frames at 0.7 EV stepTimed:12 MP, 2/3/5/7/10/15/20/30/60 s48 MP, 5/7/10/15/20/30/60 s
|
Video Resolution
H.264/H.265
4K: 3840沁2160@24/25/30/48/50/60/100*fpsFHD: 1920沁1080@24/25/30/48/50/60/100*/200*fps
|
Max Video Bitrate
H.264/H.265: 150 Mbps
|
Digital Zoom
12MP Photo: 1-2x
4K: 1-3xFHD: 1-4x
|
Supported File Systems
exFAT
|
Color Mode and Sampling Method
Normal:
8-bit 4:2:0 (H.264/H.265)HLG/D-Log M:10-bit 4:2:0 (H.265)
|
Photo Format
JPEG/DNG (RAW)
|
Video Format
MP4 (MPEG-4 AVC/H.264, HEVC/H.265)
|
Video Transmission
Video Transmission System
O4
|
Live View Quality
Remote Controller:
Up to 1080p/60fps (available when the aircraft is flying in Photo or Video mode)Up to 1080p/30fps (available when the aircraft is flying in Video mode)Up to 1080p/24fps (available when the aircraft is in standby mode on the ground)
|
Operation Frequency
2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz
|
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (CE)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
|
Max Transmission Distance
(free of interference)
FCC: 20 km
CE: 10 km
SRRC: 10 km
MIC: 10 km
|
Lowest Latency
Aircraft + Remote Controller: approx. 120 ms
|
Max Transmission Distance
(unobstructed, with interference)
Strong Interference: urban landscape, approx. 1.5-4 km
Medium Interference: suburban landscape, approx. 4-10 km
Low Interference: suburb/seaside, approx. 10-20 km
|
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Buildings: approx. 0-0.5 km
Low Interference and Obstructed by Trees: approx. 0.5-3 km
|
Max Download Speed
O4:
10 MB/s (with DJI RC-N2)10 MB/s (with DJI RC 2)Wi-Fi 5: 30 MB/s
|
Antennas
4 antennas, 2T4R
|
Charging Hub
Compatible DJI Charger
DJI 30W USB-C Charger
or other USB Power Delivery Chargers (30 W)
|
Compatible DJI Batteries
DJI Mini 4 Pro Intelligent Flight Battery
DJI Mini 3 Series Intelligent Flight Battery/Intelligent Flight Battery Plus
|
Input
5 V, 3 A
9 V, 3 A
12 V, 3 A
|
Output (USB)
Max Voltage: 5 V, Max Current: 2 A
|
Charging Type
Three batteries being charged in seequence
|
APP
Name
DJI Fly
|
Required Operating System
iOS v10.0 or later Android v6.0 or later
|
Supported SD Cards
Supported SD Cards
UHS-I Speed Class 3 or above is required.
A list of reccomended microSD cards can be found below
