Aircraft
Takeoff Weight
Approx. 1063 g
|
Dimensions
Folded (with propellers): 257.6沁124.8沁106.6 mm (L沁W沁H)
Folded (without propellers): 257.6沁124.8沁103.4 mm (L沁W沁H)
Unfolded (without propellers): 328.7沁390.5沁135.2 mm (L沁W沁H)
|
Max Ascension Speed
10 m/s (Sport Mode)
6 m/s (Normal Mode)
6 m/s (Cine Mode)
|
Max Descent Speed
10 m/s (Sport Mode)
6 m/s (Normal Mode)
6 m/s (Cine Mode)
|
Max Horizontal Speed
At sea level, in windless conditions:
25 m/s* (Sport Mode)15 m/s (tracking status)
At sea level, with 2 m/s taiwind, while flying in the same direction as the wind:
27 m/s* (Sport Mode)15 m/s (tracking status)
|
Max Takeoff Altitude
6000 m
(Maximum takeoff altitude is 3000 m with DJI Mavic 4 Pro Propeller Guards.)
|
Max Flying Time
51 minutes
|
Max Hovering Time
45 minutes
|
Max Flying Distance
41 km
|
Max Wind Speed Resistance
12 m/s (39.4 ft/s)
|
Max Pitch Angle
35‵
|
Hovering Accuracy Range
Vertical:
呼0.1 m (with vision positioning)呼0.5 m (with satelite positioning)
Horizontal:呼0.3 (with vision positioning)呼0.5 m (with satelite positioning)
|
Global Navigation Satelite System
GPS + Galileo + BeiDou
|
Operating Temperature
-10 ‵C to 40 ‵C (14 ‵F to 104 ‵F)
|
Internal Storage
Mavic 4 Pro: 64GB (available storage space is approximately 42GB)
Mavic 4 Pro 512GB (Creator Combo): 512GB (available storage space is approximately 460GB)
|
Class
C2 (EU)
|
Gimbal
Stabilization
3-axis mechanical gimbal (tilt, roll, pan)
|
Mechanical Range
Tilt: -164‵ to 160‵
Roll: -90‵ to 450‵Pan: -22‵ to 22‵
|
Controllable Range
Tilt: -90‵ to 70‵
Roll: -40‵ to 400‵
|
Max Control Speed (tilt)
Tilt: 100‵/s
Roll: 100‵/s
|
Angular Vibration Range
Hovering Without Wind: 呼0.001‵
Normal Mode: 呼0.003‵Sport Mode: 呼0.005‵
|
Sensing System
Sensing Type
Omnidirectional binocular vision system, supplemented with forward-facing LiDAR
and an infrared sensor at the bottom of the aircraft
|
Forward
Measurement Range: 0.5-24 m
Detection Range: 0.5-200 mEffective Sensing Speed: Flight Speed 沌 18 m/sFOV: Horizontal 180‵, Vertical 180‵
|
Backward
Measurement Range: 0.5-22 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed 沌 18 m/sFOV: Horizontal 180‵, Vertical 180‵
|
Lateral
Measurement Range: 0.5-21 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed 沌 18 m/sFOV: Horizontal 180‵, Vertical 180‵
|
Upward
Measurement Range: 0.5-18 m
Effective Sensing Speed: Flight Speed 沌 6 m/sFOV: Horizontal 90‵, Vertical 90‵
|
Downward
Measurement Range: 0.5-17 m
Effective Sensing Speed: Flight Speed 沌 6 m/sFOV: Horizontal 180‵, vertical 180‵
|
3D Infrared Sensing System
Forward-Facing LiDAR
Measurement Range (nighttime): 0.5-25 m (reflectivity > 10%)FOV: Up and Down 60‵, Left and Right 60‵
Downward-Facing Infrared SensorMeasurement Range: 0.3-8 m (reflectivity > 10%)FOV: Front and Back 60‵, Left and Right 60‵
|
Operating Environment
Forward, Backward, Left, Right, and Upward:
Surfaces with discernible patterns and adequate lighting (lux > 0.1, urban lighting environment)Downward:Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people),
and adequate lighting (lux > 0.1, urban lighting environment)
|
Camera
Image Sensor
Hasselblad Camera: 4/3 CMOS, Effective Pixels: 100 MP
Medium Tele Camera: 1/1.3-inch CMOS, Effective Pixels: 48 MP
Tele Camera: 1/1.5-inch CMOS, Effective Pixels: 50 MP
|
Lens
Hasselblad Camera
FOV: 72‵Format Equivalent: 28 mmAperture: f/2.0 to f/11Focus: 2 m to ?
Medium Tele CameraFOV: 35‵Format Equivalent: 70 mmAperture: f/2.8Focus: 3 m to ?
Tele CameraFOV: 15‵Format Equivalent: 168 mmAperture: f/2.8Focus: 3 m to ?
|
ISO Range
Hasselblad Camera
VideoNormal:100-12800 (Normal)400-6400 (D-Log)100-6400 (D-Log M)100-6400 (HLG)Slow Motion:100-6400 (Normal)400-3200 (D-Log)100-3200 (D-Log M)100-3200 (HLG)Photo100-6400 (25 MP)100-3200 (100 MP)
Medium Tele Camera and Tele CameraVideoNormal:100-12800 (Normal)400-3200 (D-Log)100-3200 (D-Log M)100-3200 (HLG)Slow Motion:100-6400 (Normal)400-3200 (D-Log)100-3200 (D-Log M)100-3200 (HLG)Photo100-6400 (12 MP)100-3200 (48 MP and 50 MP)
|
Shutter Speed
Hasselblad Camera
25MP Single Shot: 1/16000-16 s (over 2 s for simulated long exposure)100MP Single Shot: 1/8000-8 s25 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-8 s100 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/8000-8 s
Medium Tele Camera12 MP Single Shot: 1/16000-8 s (over 2 s for simulated long exposure)48 MP Single Shot: 1/8000-2 s12 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s48 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/8000-2 sTele Camera12.5 MP Single Shot: 1/16000-8 s (over 1 s for simulated long exposure)50 MP Single Shot: 1/16000-2 s12.5 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s50 MP Auto Exposure Bracketing (AEB)/Burst Shooting/Timed: 1/16000-2 s
|
Max Image Size
Hasselblad Camera: 12288 沁 8192
Medium Tele Camera: 8064 沁 6048Tele Camera: 8192 沁 6144
|
Still Photography Modes
Hasselblad Camera
Single Shot: 25 MP, 100 MPAutomatic Exposure Bracketing (AEB): 25 MP, 3/5/7 frames at 0.7 EV step;
100 MP, 3/5 frames at 0.7 EV stepBurst Shooting: 25 MP, 3/5/7 frames; 100 MP, 3/5 framesTimed: 25 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds;
100 MP, 2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5 (Mavic 4 Pro 512GB)/
7 (Mavic 4 Pro 512GB)/10/15/20/30/60 seconds
Medium Tele CameraSingle Shot: 12 MP, 48 MPAutomatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames at 0.7 EV step;
48 MP, 3/5/7 frames at 0.7 EV stepBurst Shooting: 12 MP, 3/5/7 frames; 48 MP, 3/5/7 framesTimed: 12 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds;
48 MP, 1 (Mavic 4 Pro 512GB)/2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5/7/10/15/20/30/60 secondsTele CameraSingle Shot: 12.5 MP, 50 MPAuto Exposure Bracketing (AEB):
12.5 MP, 3/5/7 frames at 0.7 EV step; 50 MP, 3/5/7 frames at 0.7 EV stepBurst Shooting: 12.5 MP, 3/5/7 frames; 50 MP, 3/5/7 framesTimed: 12.5 MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds;
50 MP, 1 (Mavic 4 Pro 512GB)/2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5/7/10/15/20/30/60 seconds
|
Video Resolution
Hasselblad Camera
H.264 ALL-I/H.265 Standard*6K: 6016沁3384@24/25/30/48/50/60fpsDC1 4K: 4096沁2160@24/25/30/48/50/60/120**fps4K: 3840沁2160@24/25/30/48/50/60/120**fpsFHD: 1920沁1080@24/25/30/48/50/60fps4K Vertical Shooting: 2160沁3840@24/25/30/48/50/60fpsH.264 StandardFHD: 1920沁1080@24/25/30/48/50/60fps
Medium Tele CameraH.264 ALL-I/H.265 Standard*4K: 3840沁2160@24/25/30/48/50/60/120**fpsFHD: 1920沁1080@24/25/30/48/50/60fps2.7K Vertical Shooting: 1512沁2688@24/25/30/48/50/60fpsH.264 StandardFHD: 1920沁1080@24/25/30/48/50/60fps2.7K Vertical Shooting: 1512沁2688@24/25/30/48/50/60fps
Tele CameraH.264 ALL-I/H.265 Standard*4K: 3840沁2160@24/25/30/48/50/60/100**fpsFHD: 1920沁1080@24/25/30/48/50/60fps2.7K Vertical Shooting: 1512沁2688@24/25/30/48/50/60fpsH.264 StandardFHD: 1920沁1080@24/25/30/48/50/60fps2.7K Vertical Shooting: 1512沁2688@24/25/30/48/50/60fps
* Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
* Recording frame rates. The corresponding video plays as a slow-motion video.
|
Max Video Bitrate
H.264 Standard Bitrate: 90 Mbps
H.265 Standard Bitrate: 180 MbpsH.264 ALL-I Bitrate: 1200 MbpsOnly Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
|
Digital Zoom
Hasselblad Camera: 1x to 2.5x
Medium Tele Camera: 2.5x to 6xTele Camera: 6x to 24x
|
Supported File Systems
exFAT
|
Color Mode and Sampling Method
Hasselblad Camera
Normal Color:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)8-bit 4:2:0 (H.264 Standard)HLG/D-Log M/D-Log:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)
Medium Tele CameraNormal Color:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)8-bit 4:2:0 (H.264 Standard)HLG/D-Log M/D-Log:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)Tele CameraNormal Color:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)8-bit 4:2:0 (H.264 Standard)HLG/D-Log M/D-Log:10-bit 4:2:2 (H.264 ALL-I)10-bit 4:2:0 (H.265 Standard)Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
|
Photo Format
JPEG
DNG (RAW)
|
Video Format
MP4 (H.264 ALL-I/H.264 Standard/H.265 Standard)
Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
|
Video Transmission
Video Transmission System
O4+
|
Live View Quality
Remote Controller: 1080p/30fps, 1080p/60fps
|
Operation Frequency
2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz
|
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (CE)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
|
Max Transmission Distance
(free of interference)
FCC: 30 km
CE: 15 km
SRRC: 15 km
MIC: 15 km
|
Lowest Latency
Compatible with DJI RC 2/ DJI RC Pro 2 Remote Controller:
approx. 130 ms
|
Max Transmission Distance
(unobstructed, with interference)
Strong Interference: urban landscape, approx. 1.5-6 km
Medium Interference: suburban landscape, approx. 6-15 km
Low Interference: suburb/seaside, approx. 15-30 km
|
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Buildings: approx. 0-0.7 km
Low Interference and Obstructed by Trees: approx. 0.7-4.5 km
|
Max Download Speed
O4+: 10 MB/s
Wi-Fi 6: 80 MB/s
|
Antennas
6 antennas, 2T4R
|
WiFi Protocol
802.11 a/b/g/n/ac/ax
|
Operating Frequency
2.4000-2.4835 GHz5.725-5.850 GHz
|
Transmitter Power (EIRP)
2.4 GHz:< 23 dBm (FCC)< 20 dBm (CE/SRRC/MIC)5.8 GHz:< 23 dBm (FCC/SRRC)< 14 dBm (CE)
|
Bluetooth Protocol
Bluetooth 5.1
|
Operating Frequency
2.4000-2.4835 GHz
|
Transmitter Power (EIRP)
< 10 dBm
|
Charging Hub
Input
USB-C Port: 5 V to 20 V, max 5 A
Mini SDC Port: 11.2 V to 17.6 V, max 15 A
|
Output
Battery Port: 10 V to 17.2 V, max 12 A
|
Rated Power
USB-C Port: Supports up to 100 W
Mini SDC Port: Supports up to 240 W/15 A
|
Charging Type
When used with the DJI Mavic 240W Power Adapter: Supports parallel charging of three batteries
(The Parallel Charging Hub will prioritize the battery with the lowest charge and
switch to parallel charging once all three batteries reach the same charge level.)When used with the DJI 100W USB-C Power Adapter: Charges three batteries at the same time.
|
Compatibility
DJI Mavic 4 Pro Intelligent Flight Battery
|
Battery
Capacity
6654 mAh
|
Weight
Approx. 332 g
|
Nominal Voltage
14.32 V
|
Max Charging Voltage
17.2 V
|
Battery Type
Li-ion 4S
|
Chemical System
LiNiMnCoO2
|
Energy
95.3 Wh
|
Operating Environment
5‵ to 40‵ C (41‵ to 104‵ F)
|
Charging Time
Using the DJI Mavic 240W Power Adapter with no other devices connected
to the charger or the Charging Hub’s USB-C port
From 0% to 100%: 1 battery takes about 51 minutes, 3 batteries take about 90min
(200 V to 240 V input) or about 110 minutes (100 V to 127 V input)
Using DJI 100W USB-C Power AdapterFrom 0% to 100%: 1 battery takes about 80 minutesCharging via the aircraft (65W max charging power)From 0% to 100%: 115 minutes
