XF C-20D Vertical 19mm 2-Axis FPV Gimbal for DJI O4/O4 Pro Cameras, Compatible with RC Drones

Description

XF C-20D Vertical 19mm 2-Axis FPV Gimbal Supports DJI O4/ O4 PRO Camera for FPV RC Drones

The XF C-20D Vertical 19mm 2-Axis FPV Gimbal is designed for seamless integration with DJI O4 and O4 Pro cameras, offering wide compatibility with digital FPV systems and 19mm analog cameras. Constructed from high-performance polymer, this lightweight gimbal features advanced 2-axis mechanical stabilization with high-torque motors, ensuring exceptional stability against vibrations and high-speed impacts. It supports multiple control options, including Headtracker, UART, S.BUS, CRSF, and PWM, and can be mounted downward or upward. With a wide voltage input range of 7.4 to 26.4 VDC, it is versatile for various power sources. Ideal for RC drones, cars, and planes, the XF C-20D offers flexible mounting and control for diverse applications.

Features

– Wide Compatibility: Compatible with various digital FPV systems, including DJI O4 Pro, DJI O4, and 19mm wide analog cameras or similar devices.
– Durablee Material: Made of high-performance polymer, ensuring a lightweight and compact design.
– Advanced Stabilization: Equipped with a 2-axis mechanical stabilization structure and high-torque motors, providing exceptional stability against vibrations and high-speed air impacts.
– Multiple Stabilization Modes: Suitable for various platforms such as RC cars, FPV fixed-wing planes, and realistic RC planes.
– Versatile Control Options: Supports Headtracker, UART (private protocol & MAVLink), S.BUS, CRSF, and PWM control.
– Flexible Mounting: Can be mounted either downward or upward to suit different application needs.
– Wide Voltage Input: Compatible with 7.4~26.4 VDC input, making it versatile for various power sources.
– The XF C-20T 3-Axis FPV Gimbal for DJI O4/O4 Pro works seamlessly with the HeadTracker Integrated Baseboard All-In-One Edition, enabling integrated operation.

General

Product Name

C-20D O4/ O4 Pro

Dimensions (with damper)

42 x 50.9 x 55.7mm

Weight (with damper)

36g

Operating Voltage

7.4 ~ 26.4 VDC

Power

0.25W (Static) / 8W (Stall)

Mounting

Downward / Upward

Control Port

Headtracker / UART (private protocol & MAVLink) / S.BUS / CRSF / PWM

Gimbal

Gimbal Type

2-axis Mechanical Stabilization

Angular Accuracy

呼0.005‵

Controllable Range

Pitch: -30‵~+175‵, Yaw: 呼145‵

Max Rotation Speed

呼1500‵/s

Camera Suitability

Maximum Weight

20g

Maximum Width

19mm

Package Included:
1 x XF C-20D Vertical 19mm 2-Axis FPV Gimbal
