PandaRC VT5804-BAT Max FPV Transmitter, 5.8W 64CH, 6-36V, OSD Adjustment, for FPV Racing Drones

Description

PandaRC VT5804-BAT Max 5.8W 64CH 4.9G 5.8G 6G VTX 6-36V FPV Transmitter Support OSD Adjustment Image Transmission for FPV Racing Drones

The PandaRC VT5804-BAT Max FPV Transmitter is designed for FPV racing drones, offering adjustable power transmission from 50mW to 5800mW. This flexibility allows for customizable signal strength to suit various applications and enhance transmission range. With a 64-channel frequency range, it ensures stable and interference-free connections. The transmitter supports a wide input voltage range of 6-36V, making it compatible with diverse drone setups. Weighing only 58g, its compact design facilitates easy installation. Additionally, it automatically detects NTSC and PAL video formats for seamless video transmission. The VT5804-BAT Max is equipped with an SMA internal foramen antenna interface and features convenient parameter tuning via buttons or OSD.

Specification:

Brand:

PandaRC

Product Name:

VT5804-BATMax

Output Power:

0-50-500-1000-2500-5800mW

Input Voltage:

6藩36V

Parameter Tuning:

Buttons/OSD

Operating Current:

1W/ 12V@, 1000ma; 5.8W/ 12V@, 2000ma

Output Frequency:

64CH (A藩B藩E藩F藩R藩X藩L藩S)

Antenna interface:

SMA internal foramen

Mounting Holes:

20*20mm藩30.5*30.5mm

Video Format:

NTSC/PAL automatic detection

Weight:

58g (without antenna and power cord)

Dimensions:

Length 60mm * Width 40mm * Height 16.5mm

Features:
1. Adjustable Power Transmission: Supports multiple power outputs from 50mW to 5800mW, enabling customizable strength for various applications and extended transmission ranges.
2. 64-Channel Frequency Range: Offers wide compatibility with 64 selectable channels across frequency bands from A-S, ensuring stable and interference-free connections.
3. High Compatibility Voltage Input: Operates with a versatile input voltage range of 6-36V, suitable for varied drone setups and FPV devices.
4. Lightweight Compact Design: Weighs only 58g without accessories, with dimensions of 60mm*40mm*16.5mm, delivering portability and easy installation.
5. Automatic Video Format Detection: Compatible with NTSC/ PAL formats, ensuring seamless video transmission across diverse standards.

Package Included:
1 x VT5804-BAT Max
