RX42BRB Multi-protocol 6CH Mini Compatible RC Receiver with Dual Brushed 7.5A ESC for Flysky Wfly Microzone Radio Transmitter
The RX42BRB Multi-protocol 6CH Mini RC Receiver is designed with dual brushed 7.5A ESCs, making it ideal for Flysky, Wfly, and Microzone radio transmitters. This compact receiver supports multiple protocols, including AFHDS, AFHDS2A, WLY2, and MC6C, allowing for automatic binding. It operates within a voltage range of 3.7V to 8.4V (1-2S Lipo) and supports PPM and SBUS signals. Additionally, it can handle up to 30 WS2812B LED strips, providing versatile lighting options. The receiver’s lightweight design, weighing only 4.2g, makes it suitable for various RC applications.
RX42BRB Multi-protocol 6CH Mini Compatible RC Receiver with Dual Brushed 7.5A ESC for Flysky Wfly Microzone Radio Transmitter
Specification:
Item Name: RX42BRB Receiver
ESC Type: Dual Channel Brushed ESC
Maximum ESC Output: 7.5A per channel
Supported Protocols: AFHDS, AFHDS2A, WLY2, MC6C
Voltage Range: 3.7V – 8.4V (1-2S Lipo)
Supported Signals: PPM, SBUS
LED Support: 30 WS2812B LED Strips
Dimensions: 18*35mm
Weight: 4.2g
Features:
1. 2 built-in ESC for brushed motor, MAX 7.5A each, differential outputs supported.
2. Support 4 protocols, AFHDS, AFHDS2A, wly2(wfly ET series) and mc6c, Automatic binding.
3. Wide range voltage supply 3.7-8.4V(1-2s lipo) supported.
4. IntVoltage ext’Voltage, RSSI and error rate telemetry supported.
5. PPM and SBUS supported.
6. 30 WS2812b Strips LED supported.
Package Included:
1 x RX42BRB Receiver
