Axisflying Manta 5 Pro 5-Inch Carbon Fiber Frame Kit for DJI O4 Pro, Freestyle RC FPV Racing Drone

Sale!

Axisflying Manta 5 Pro 5-Inch Carbon Fiber Frame Kit for DJI O4 Pro, Freestyle RC FPV Racing Drone

Price range: 163.23$ through 167.97$

Durable T700 carbon fiber construction
Compatible with DJI O4 Pro for seamless integration
Supports up to 5.1-inch propellers
226.5mm wheelbase for optimal balance
Lightweight design at 219g including exterior parts

SKU: RC2035705 Category: Multi Rotor Parts Tags: 5-inch carbon fiber frame, Axisflying MANTA 5 PRO, DIY drone building, DJI O4 PRO compatible, FPV racing drone kit, freestyle RC drone frame, lightweight drone frame, T700 carbon fiber drone Brand: Axisflying

Description

Axisflying Manta 5 pro Squashed X / DC 5 Inch Carbon Fiber Frame Kit Support DJI O4 Pro for DIY Freestyle RC FPV Racing Drone

The Axisflying Manta 5 Pro Frame Kit is expertly designed for DIY enthusiasts and freestyle RC FPV racing drones. This durable frame is crafted from T700 carbon fiber, ensuring high strength and light weight. With a wheelbase of 226.5mm, the frame offers a top plate of 2mm and a bottom plate of 3mm, complemented by 6mm thick arms. It includes mounting holes compatible with DJI O4 Pro, providing seamless integration for your VTX and camera setup. The frame supports motor mounting holes of 16mm x 16mm and can accommodate propellers up to 5.1 inches. Ideal for those seeking precision and performance in their drone builds, the Manta 5 Pro is a top choice for racing enthusiasts.

Specification:
Brand: Axisflying
Model: Manta 5 PRO
Item Name: Manta 5 Pro DC Frame Kit / Manta 5 Pro Squashed X Frame Kit

Item

Specification

Manta 5 Pro DC Frame Kit

Structure: DC
Wheelbase: 226.5mm
Top Plate: 2mm
Bottom Plate: 3mm
Arm Thickness: 6mm
Carbon Fiber Grade: T700
Stack Height: 23mm
Camera Thickness: 19mm, 20mm
stack Mounting Holes: 20mm20mm / M3
VTX Mounting Holes: O4 PRO compatible only
Motor Mounting Holes: 16mm*16mm / M3
Prop Mounting Holes: Max 5.1 inch
Frame Weight: 219呼5g (including exterior parts and aluminum parts)

Manta 5 Pro Squashed X Frame Kit

Structure: Squashed X
Wheelbase: 226.5mm
Top Plate: 2mm
Bottom Plate: 3mm
Arm Thickness: 6mm
Carbon Fiber Grade: T700
Stack Height: 23mm
Camera Thickness: 19mm, 20mm
stack Mounting Holes: 20mm20mm / M3
VTX Mounting Holes: O4 PRO compatible only
Motor Mounting Holes: 16mm*16mm / M3
Prop Mounting Holes: Max 5.1 inch
Frame Weight: 215呼5g (including exterior parts and aluminum parts)

Recommended Parts(Not included):
Motor: Axisflying AE2207 V2 2207 1960KV 6S Brushles Motor / GEPRC SPEEDX2 2207 1960KV 6S Brushless Motor
VTX & Camera: DJI O4 Pro Air Unit
FC & ESC: Axisflying Argus Mini 55A
Propeller: 6 Pairs iFlight Nazgul F5 5.1Inch 3-blade Propeller
Battery: 6s 1050藩1550 mAh

Package Included:
1 x Frame Kit
