30.5*30.5mm MAMBA MK4 H743 V2 3-6S Flight Controller for FPV Racing RC Drone
Description:
MCU: 480MHz STM32H743
GYRO: DUAL ICM-42688-P
Targetspan >MAMBA H743_2022B
OSD: Yes
Blackbox: 128M Flash Memory
Barometer: SPL06
Uarts: 8Set
I2C: Yes
F.Port: Yes
RSSI: No
Buzzer Pad: Yes
CURR Pad: Yes
ESC Signal: 8 Set
ESC Soft: Dshot300/600/1200
ESC Telemetry: Yes
Power Led: Yes
LED Controller: BF LED/MB LED
AIR UNIT Port: Yes
WIFI: SpeedyBee APP
VTX Switch: Yes
Receiver Protection: Yes
TVS Protection: Yes
BEC:3.3V 0.5A& 5V 3A& 9V 3A
Input: 3~6S Lipo (12.6~25.2V)
Mounting size: 30.5mm/M3
Package Included:
1* MAMBA MK4 H743 V2 Flight Controller
Additional information
| Weight | 0.026 kg |
|---|
