30.5×30.5mm JHEMCU GHF722AIO ICM F7 Flight Controller with 5V BEC Output AIO 40A BL_S 4IN1 ESC 2-6S for FPV Racing RC Drone

Original price was: 107.05$.Current price is: 87.03$.

SKU: RC1981529 Category: Multi Rotor Parts

Description

30.5×30.5mm JHEMCU GHF722AIO ICM F7 Flight Controller with 5V BEC Output AIO 40A BL_S 4IN1 ESC 2-6S for FPV Racing RC Drone

Specification:
Brand: JHEMCU
Model: GHF722AIO ICM
Item Name: F7 Flight Controller AIO 40A ESC

F7 Flight Controller

MCU: STM32F722/21 6MHZ
IMU: ICM-42688-P /Gyro/Accel
OSD: AT7456E
Barometer: Yes
Blackbox: 8MB
Input Voltage: 2-6S
BEC: 5V 2.5A ( +-0.1V)
Receiver: Support ELRS(CRSF), TBS(CRSF) ,SBUS,IBUS,DSM2,DSMX
IIC: YES
USART: UART1/UART2/UART3/UART4/UART5/UART6
Led_ Strip: YES
Buzzer: Support 5V active
USER1 Mode: Support, PINIO Pad output
Current Port: YES
Voltage sensor: YES
DFU Button: YES
USB: Micro USB
Firmware: betaflight_ 4.3.0 JHEF7DUAL.HEX
Size: 33x33mm ( Mounting Hole: 25.5-26.5*3mm)
Weight: 7.3g

40A 4in1 ESC

Con. Current: 40A
Burst Current: 45A
MCU: EFM8BB21F16G
Type: Bluejay / Blheli_ S
ESC Firmware: BluejayG_ H 30_ 48_ v0.16.hex
ESC signal: PWM,Oneshot125,Oneshot42,Multishot,Dshot150,Dshot300,Dshot600

Package Includes:
1x GHF722AIO ICM Board
1x Soldering Practice Board
1x Red Cable
1x Black Cable
1x Capacitor
4x Rubber shock absorber
1x Connector

Additional information

Weight	0.038 kg

Reviews

There are no reviews yet.
