GEPRC MATEN 5.8G 3W 80CH VTX PRO FPV Transmitter with Dual Mounting Holes and IRC Tramp MMCX Antenna for FPV Racing Drones

Description

GEPRC MATEN 5.8G 3W 80CH VTX PRO Long Range Image Transmission FPV Transmitter Dual Mounting Holes IRC Tramp MMCX Antenna Supports OSD for FPV Racing Drones

The GEPRC MATEN 5.8G 3W VTX PRO is a cutting-edge FPV transmitter designed for long-range image transmission. It features a dual-core design capable of delivering up to 3000mW for stable signal transmission and superior penetration. The high-strength CNC aluminum shell enhances heat dissipation and impact resistance, while the integrated fan cooling ensures optimal performance. This VTX supports the IRC Tramp protocol for easy OSD parameter adjustments and includes a built-in microphone for real-time audio transmission. With a wide voltage input range of 7-36V and temperature protection, it is built to prevent overheating. It offers 80 transmission channels and supports two mounting hole sizes, making it versatile for various drone builds.

Summary券
The MATEN 5.8G 3W VTX PRO is a high-performance VTX newly developed by the GEPRC team. With five adjustable power options and a dual-core design, it delivers up to 3000mW of power, ensuring stable signal transmission and excellent penetration.
Built with a high-strength CNC aluminum metal shell, the MATEN 5.8G 3W VTX PRO offers superior heat dissipation and impact resistance. Its sleek design features a fan cooling function for optimal performance, while the built-in micrphone transmits real-time audio from the FPV drone.
Supporting the IRC Tramp protocol, it allows you to adjust parameters through OSD. It operates within a voltag extent of 7-36V and includes temperature protection to prevent overheating and damage. With 80 transmission channels and two mounting options, 20x20mm (M2) and 30.5沁30.5mm (M2), itㄙs the perfect VTX for any build.

Feature券
– Dual-core design, up to 3000mW, suitable for long extent fligh
– The well-chosen high-strength aluminum metal CNC shell assist heat dissipation
– The built-in micr turbofan dissipates heat actively
– Wide voltag input supports 7V-36V voltag input
– One function adjustment buttons, three indicator lights, easy to operate.
– VTX control protocol IRC Tramp supports OSD parameter adjustment.
– Temperature control protection function prevent overheat
– VTX built in micrphone,real-time transmission of sounds.
– Supports 80 transmission channels
– Support 20x20mm(M2) and 30.5沁30.5mm(M2) two different mounting hole sizes
Specifications券

Model:

GEPRC MATEN 5.8G 3W VTX PRO

Frequency券

5.8G

Channels:

80CH

Output power:

25mW/200mW/600mW/1600mW/3000mW/Pit mode

Input voltag:

DC7-36V侈2-8S Battery佩

Output Voltag:

5V@600mA

Protocol:

IRC Tramp

Antenna Connector:

MMCX

Cable Connector:

SH1.0 6pin

Video Format:

PAL/NTSC

Micrphone:

Built-in micrphone

Weight:

21.1g

Mounting Hole Size券

20x20mm(M2),30.5沁30.5mm(M2)

Dimension:

36.3沁36.3沁15.1mm

Package Included:
1 x GEPRC MATEN 5.8G 3W VTX PRO
