T-Motor VELOX VELOCE SERIES V2207.5 V2 2207.5 1750KV 1950KV 6S / 2550KV 4-5S Brushless Motor for RC Drone FPV Racing
Specification:
Brand Name: T-Motor
Model: Velox VELOCE SERIES
V2207.5 V2
Item Name:
2207.5 1750KV 1950KV 6S / 2550KV 4-5S Brushless Motor
KV: 1750KV/ 1950KV / 2550KV (Optional)
Quantity: 1 PC
Version: CW Screw Thread
Input Voltage: 6S (1750KV & 1950KV ); 4S ( 2550KV)
Shaft Diameter:5mm
Configuration: 12N14P
Motor Dimension: 27.6×31.45mm (Dia*Len)
Cable Length: 150mm, 20AWG
| Optional KV | 1750KV | 1950KV | 2550KV |
| Input Voltage | 6S | 6S | 4-5S |
| Internal Resistance | 74m?? | 53.5m?? | 41m?? |
| Idle Current (10V) | 1.15A | 1.42A | 1.95A |
| Peak Current ( 60S) | 35.7A | 39A | 38.1A |
| Max. Power ( 60S) | 794W | 873W | 557W |
| Weight ( Include Cable) | 34.6g | 35.3g | 35.6g |
| Weight (Exclude Cable) | 30.8g | 31.5g | 31.6g |
Package Included:
1x T-Motor Velox VELOCE V2207.5 V2 Motor
1x Motor Nut
1x bag of Screws
Additional information
| Weight | 0.031 kg |
|---|---|
| KV: No selection | 1750KV, 1950KV, 2550KV |
