BETAFPV Air65 II 65mm 1S Brushless Whoop Frame Kit for RC Micro FPV Racing Drone
The BETAFPV Air65 II Brushless Whoop Frame redefines agility and resilience for RC micro FPV racing drones. Weighing just 2.65g, this frame features a redesigned structure with four arm braces and optimized duct geometry, increasing thrust by 5% while maintaining durability. The frame’s PP matrix material effectively absorbs crash impacts, ensuring worry-free flying. Enhanced details include motor fixed slots, motor screw protection, enlarged FC mounting holes, and a lowered duct profile, all engineered for high performance. Experience reliable flight with near-perfect PID response and reduced vibration for smooth maneuvers.
Description:
For nearly two years, the Air65 Frame defined lightweight agility. Now, forged alongside our global pilot community, the 2.65g Air65 II Frame reimagines the form. Our R&D team deconstructed every arm brace, duct geometry, and crash point. The result A radcal yet refined frame: 4 arm braces replace 6, paired with optimized ducts and connecting structure. This shaves frame amplitude while adding 5% thrust and delivering near-perfect PID response. Beneath the form lies resilence. An optimized PP matrix absorbs brutal impacts from crashes. Refined details 藩 screw protection structure, enlarged FC holes, and a lowered duct profile 藩 ensure dominance. All engineered for relentless, worry-free flying.
Bullet Points
– Arm braces reduced from 6 to 4 + optimized duct geometry increase 5% thrust – while maintaining uncompromising durability.
– Optimized connecting braces reduce frame amplitude and achieve ideal PID step response.
– Optimized PP blend makes it crash ready.
– Pilot-Focused Details: Motor fixed slots, motor screw protection structure, enlarged FC mounting holes (25.5 沁 25.5mm), and lowered duct profile.
Frame Reshaped: +5% Thrust:
By strategically reducing arm braces from 6 to 4 and refining duct aerodynamics, the Air65 II achieves 5% higher thrust versus Gen 1 – delivering instant throttle response and sustained power for the quadcopter.
Reliable Flight
After dozens of structural refinements, our final connecting arms design effectively reduce frame vibration. Paired with Feedforward tuning, this achieves a near-perfect PID step response with <12ms lag – translating to crisp maneuvers and buttery-smooth freestyle flow.
Optimized Resilient Material:
Our battle-tested PP blend laughs off concrete kisses and tree bites. Survive your most violent freestyle crashes – and fly home.
Details Matter
Every gram perfected: Retained motor fixed slots ensure precise alignment, new motor screw protection structures deflect crash impacts, enlarged 1.2mm FC holes fit 1.4mm screws effortlessly, and our 12.4mm lowered ducts (-0.6mm) plus 3.8mm slim profile clear short-can motors. Where pilot priorities meet engineering obsession.
Specification:
Brand: BETAFPV
Item: Air65 II Brushless Whoop Frame
Material: PP
Weight: 2.65g
Wheelbase: 65mm
Motor Mounting: 3-M1.4-6.6mm
Flight Controller Mounting Hole: 25.5沁25.5mm
Battery Slot Size: 11.4沁6.2mm
Maximum Size: 82.6*82.6*15.1mm
Color: Black, Transparent Blue, Transparent Orange, Transparent Purple, Transparent White
Recommended Parts(Not included):
Battery: 1S 260mAh 80C Battery, 1S 300mAh 75C Battery
FC: Air Brushless Flight Controller, Matrix 1S Brushless Flight Controller (3IN1/4IN1), Matrix 1S Brushless Flight Controller (5IN1)
Motors: 0702 II Brushless Motors, 0802SE Brushless Motors
Canopy: Air Canopy, Canopy for Micro Camera 2022, Micro Canopy Lite
Propellers: GF 1219S 3-Blade Propellers, HQ 31mm Ultralight 3-Blade Propellers
Screws: Meteor Series Motor Fixing Screws Pack (40PCS)
Package Included:
1 x Air65 II Brushless Whoop Frame
