Diatone Roma5 DJI Version 226mm Wheelbase 5 Inch Type-H Frame Kit for RC FPV Racing Drone 20*20mm/30.5*30.5mm
The Diatone Roma5 DJI Version Frame Kit is expertly designed for RC FPV racing drones. Featuring a robust Type-H frame shape, it offers a 226mm wheelbase and is crafted with precision from durable materials. The frame includes a medium plate thickness of 2mm, arm thickness of 5mm, and top and bottom plates each measuring 2.5mm. With a side plate thickness of 1.5mm and an arm width ranging from 10 to 12mm, this frame ensures stability and strength. It supports a maximum stack height of 23mm and accommodates motor hole distances of 16mm. The package includes injection parts such as a camera metal mount protector, arm protector, and a universal adjustable GoPro mount.
Specification:
Brand:DIATONE
Item Name: Roma5 DJI Version
Frame Shape: Type-H
Medium Plate Thickness: 2mm
Arm Thickness: 5mm
Wheelbase: 226mm
Top Plate Thickness: 2.5mm
Bottom Plate Thickness: 2.5mm
Side Plate Thickness: 1.5mm
Arm Width: 10~12mm
Max Stack Height: 23mm
Frame Net Weight: 135g
Motor Hole Distance: 16mm
Bore Diameter of Snap Ring: 5.5mm
FC Stack Mount: 20*20mm(M3)/30.5*30.5mm(M3)
Injection Part券Camera Metal Mount Protector 佾Arm Protector佾Univeral Adjustable Gopro Mount
Package Included:
1 x DIATONE Roma5 DJI Version Frame Kit
